Leader in Inverter Welding
Features:
- Clear and reliable digital display of welding current
- Protection against over-voltage and over-current
- Advance Inverter Technology
- High Efficiency and Energy Saving
- East to start arc, stable welding current with fast response
- Silent, little spatter and magnetic bias, nice form of welded seam
- Suitable for welding metals such as stainless steel, carbon steel and copper
- AC Function TIG Welding for Welding Aluminum (Unique Use )
Specifications
| Voltage | 1 Phase AC220V |
| Frequency (Hz) | 50/60 |
| Rated Input Current | TIG: 39A | MMA: 43.6A |
| Output Current (A) | TIG: 10-250 | MMA: 10-200 |
| No-load Volt. | 56V |
| Rated output voltage (V) | TIG: 20 | MMA: 28 |
| AC Duty Cycle | 20-80% |
| Pulse duty cycle (%) | 10-90 |
| Power Factor | 0.73 |
| Post flow time (s) | 0-10 |
| Pulse frequency (Hz) | 0.5-5.0 |
| Basic value current (A) | 5-250 |
| Arc initiation current (A) | 5-250 |
| Attenuation time (S) | 0-15 |
| Arc initiation way | HF |
| Frequecy (%) | 80 |
| Power Factor | 0.73 |
| Insulation Grade | F |
| Protection Grade | IP21 |
| Max Welding Thickness | 10mm |
Inclusions:
TIG Torch Assembly, Ground Clamp
* Electrode Holder not included
6 Months Service Warranty
