Kobewel XI500 MIG/MAG Inverter Welding Machine 500A

Kobewel XI500 MIG/MAG Inverter Welding Machine 500A

With  Separate Feeder

Welding Range 100 - 500 A
Load Voltage  19 - 39 V
Open Circuit Voltage 63 V
Welding Current Duty
Cycle (40°C) 100%
Input Power 24.7 kVA
Input Current 37.5A
Input Phase 3 Ph
Main Voltage, Tolerance 220 V + 15 %
Frequency 50 / 60 Hz
Weldable Steel Wire  0.8 - 1.6 mm
Weldable Aluminum Wire 0.8. 1.6 mm
Power Factor 0.93
Efficiency 0.85
Index Protection IP 23
Insulation Class F
Cooling Type F
Dimension 650 x 360 x 470 mm
Weight 43 Kg

Inclusion:

• 1 pc WF-500 -Euro Style Wire Feeder
• 1 pc Drive Roller (0.8 mm• l1.0nm)
• 5 meters Rubber Hose (35 mm )
• 2 meters Gas Hose with Clamps
• 3 meters Welding Cable with Ground Clamp 70 - 95 Connector
• 1 set MIG Torch (500 A) 3 m Euro Connector
• 1 pc KGW-Bl Kobewel Welding Glass
