Mitutoyo Bore Gage Series 526, (with Dial Indicator for extra small holes)

₱134,200.00
-
 Precision is our Profession

Mitutoyo Bore Gage Series 526, (with Dial Indicator for extra small holes)

  • These bore gages measure diameters of small holes. The radial displacement
    of split-ball contact is converted to axial displacement of measuring rod, which is
    shown on the dial indicator.
Bore Gage Series 526, (with Dial Indicator for extra small holes)
Code Probe Depth / Indicator Range Graduation Price
Metric
526-172 11.5mm / 2109E-10 0.95-1.55mm 0.001mm 134,200.00
526-162 22.5mm / 2109E-10 1.5-4mm 0.001mm 170,100.00
526-152 32mm / 2109E-10 3.7-7.3mm 0.001mm 106,200.00
526-173 11.5mm / 2046E-08 0.95-155mm 0.01mm 130,200.00
526-163 22.5mm / 2046E-08 1.5-4mm 0.01mm 166,400.00
526-153 32mm / 2046E-08 3.7-7.3mm 0.01mm 102,200.00
526-126 56mm / 2046E-08 7-10mm 0.01mm 18,700.00
526-127 62mm / 2046E-08 10-18mm 0.01mm 19,600.00
